3GPP Decoder is an open source tool to decode LTE, UMTS and GSM messages, and protocols. The decoder uses Wireshark to decode most of the Layer 3 messages (RRC/NAS). Download 3GPP Decoder for Windows OS 3GPP Decoder for Linux OS – Coming Soon Supported Protocols and Messages How to Install 3GPP Decoder? Prerequisite: Before installing 3GPP Decoder you need to (more.).

Download Qxdm Tools

3GPP Decoder is an open source tool to decode LTE, UMTS and GSM messages, and protocols. The decoder uses Wireshark to decode most of the Layer 3 messages (RRC/NAS).

Download 3GPP Decoder for Windows OS3GPP Decoder for Linux OS – Coming Soon


Supported Protocols and Messages

RATMessage/PDU
LTERRC BCCH.BCH
RRC BCCH.DL.SCH
RRC DL.CCCH
RRC DL.DCCH
RRC PCCH
RRC UL.CCCH
RRC UL.DCCH
NAS EPS
UMTSRLC-AM
RLC-UM
NAS
RRC BCCH.BCH
RRC BCCH.FACH
RRC DL.CCCH
RRC DL.DCCH
RRC DL.SHCCH
RRC MCCH
RRC MSCH
RRC PCCH
RRC UL.CCCH
RRC UL.DCCH
RRC UL.SHCCH
RRC SIs (SIBs and MIB)
GSMGAN TCP
GAN UDP
GSM CCCH
GSM SACCH
LLC
NAS
SNDCP
SNDCPXID

Download Qxdm Toolbar

How to Install 3GPP Decoder?

Tool

Prerequisite:

Before installing 3GPP Decoder you need to install Wireshark. Download Wireshark from this location: https://www.wireshark.org/download.html

Download Qxdm Tool Software

When installing Wireshark, also install PCAP. (Wireshark will ask during installation if you want PCAP or not).

After installation checks the directory where Wireshark is installed.

Download 3GPP Decoder and then run the Setup.exe.

After installation, you need to check File >> Preference for Wireshark path. If not correct change it.

How to use 3GPP Decoder?

I have tried to keep the user interface simple. To decode a message just follow these steps:

1. Enter the HEX string in the top text box.
2. Select the access technology (LTE, UMTS or GSM). By default when the program starts it is selected as LTE
3. Select the message type from the drop down combo box
4. Press decode.

Troubleshooting

If for some reason you can not see any output, you may check the following.

Download qxdm tool software

1. Correctly paste the HEX string and check if the selected message is correct
2. Check Wireshark path. Use the File >> Preference to set the Wireshark path.

3GPP Decoder Source Code

Get the source code from : https://github.com/panigrahip/3GPPDecoder

Download Qxdm Tool Windows 10

Thanks Vincent Helfre for providing the original idea and code of 3GPP Decoder.
